Video Laryngoscope is ready

Published:2019-12-02Author:ChloeSource:Views:643


LTVL04 Reusable Video Laryngoscope with different blades

Rich stock, fast delivery!




Features:

Anti fog coating on distal lens

Video/Photo function
Battery rechargeable
One button Only, Fast and simple operation
360 °All sight LCD, no blind spot

Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.

LTVL04 Reusable Video Laryngoscope reusable blades Parametric diagram:



Name

Technical names

Technical indicators

Machine parameters

Displayer

3.0"(LCD)



Angle of vision

≥60º



Charging times

>300times



Resolution

1280*720p



Power consumption

<2W



Illuminance

&ge;150 LUX



Rotating angles of the monitor in front & rear

0 &ordm;~130 &ordm;



Weight

220g



Image/ Video function

USB output



Memory type

Micro SD card 8GB

Charger

Charger input

110V~220V50Hz



Charger output

4.2V500mA



Charging time

<4(hrs)

Working environments

Temperature

-5&#8451;~+50&#8451;



Humidity

10%~90%



Atmospheric pressure

860~1060hpa

Storage environments

Temperature

-40&#8451;~50&#8451;



Humidity

&le;93%



Atmospheric pressure

500~1060hpa




Blade

Mil0

Mac1

Mac2

Mac3

Mac4

D-blade

Group

Neonate

Pediatric

Small adult

Adult

Large Adult

Difficult airway

tracheal tube ID(mm)

2.5-4.0

4.0-6.0

5.0-6.0

6.0-9.0

7.5-10.0

7.5-10.0

Length(cm)

8.2

10.45

12.11

14.25

16.08

13.27

Sterilization method

overall soaking in 2% glutaral or 0.5%~0.6% Cidex OPA 10 minutes

Hydrogen peroxide low temperature plasma disinfection
