Hematology analyzer
We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive.
Golden Standard Of Diabetes Diagnose
Glycosylated hemoglobin(HbA1c) is widely recognized as a Golden Standard to monitor diabetes, which can indicate the average plasma glucose concentration cover 2-3months.
Hb Variants detection of Thalassemia
Hb Variants can be detected with same column & Buffer kit as HbA1c mode or HbA2/F mode, it helps to get more accurate HbA1c results without variants interference, and also helps patients to understand their gene default to save high cost for gene test.
Methodology | High-performance Liquid Ion-exchange Chromatography(HPLC) |
Sample Type | Venous Blood, Finger Peripheral Blood, or Hemolyse blood |
Sample Volume | 5µl Whole blood, or Lyse blood (Ratio 5µl: 1000 µl) |
Sample Rack | 10 Positions, Available for Primary Tube and Sample Cups |
Test Mode & Speed | Fast Mode: 90 Secs/Test Variant Mode: 145Secs/Test β-Thalassemia(A2/F) Mode: 300 Secs/Test |
Measurement Range | HbA1c: 3-25%, HbF: 0.3-45%, HbA2: 0-15% |
Precision | CV≤1.5% |
Parameter | NGSP, IFCC Result HbA1a, A1b, HbF, LA1c, A1c(stable A1c), A0, HbA2, Hb Variants(S, C, D, E, J…) |
Photometer | 415nm LED, 20000 Hours Life Span |
Column Capacity | 4000 Tests, Up to 10,000 Tests |
Pre-sieve | 300 -400 Tests |
Information Input | Built-in Bar-code Scanner or Touch Keyboard |
Display | 10.4’ TFT colorful LCD Touch Screen |
Storage | 50,000 Test Results or 7,500 Results with Curves |
Printer | Thermal Printer or External Printer |
Data Transfer | USB port, Support LIS/HIS, Independent PC software |
Work Condition | Temperature 5~38℃, Humidity 30%~75% |
Power supply | 110V-220V, 50-60Hz |
Dimension | 310mm×470mm×500mm |
Weight | 20KG |
