Features:

1. Applicable syringe: 12 brands for user-defined

2. Occlusion sensitivity: adjustable

3. Can be stacked up and integrated into multi-channel

4. Syringe size: 10, 20, 30, 50 ml

5. Accuracy: ±2%

6. Flow rate: 0.1-1300 ml/h

7. KVO rate: 0.1-1 ml/h in 0.1 ml/h increments, adjustable

Technical Specifications OF Portable Medical ICU Syringe Pump

Model	Syringe Pump
Syringe Size	10, 20, 30, 50 ml
Applicable Syringe	2 brands built-in (BD, B. Braun), 10 brands for user-defined
Volume	0.1- 9999 ml <1000 ml in 0.1 ml increments ≥1000 mL in 1 ml increments
Flow Rate	Syringe 10 ml: 0.1- 400 ml/h Syringe 20 ml: 0.1- 600 ml/h Syringe 30 ml: 0.1- 900 ml/h Syringe 50 ml: 0.1-1300 ml/h <100 ml/h in 0.1 ml/h increments or decrements ≥100 ml/h in 1 ml/h increments or decrements
Bolus Rate	Syringe 10 ml: 400 ml/h Syringe 20 ml: 600 ml/h Syringe 30 ml: 900 ml/h Syringe 50 ml: 1300 ml/h
Accuracy	±2%
Infusion Mode	Flow rate: ml/min, ml/h Time-based Body weight: mg/kg/min, mg/kg/h, ug/kg/min, ug/kg/h
KVO Rate	0.1 -1ml/h in 0.1 ml/h increments or decrements, adjustable
Alarms	Occlusion, syringe drop off, near empty, end program, low pressure, end battery, AC power off, motor malfunction, unattended pump, syringe moved accidently, pressure sensor error
Additional Features	Syringe identification, bolus, real-time shift totals, occlusion pressure release, mute, automatic power switching, residue reminder, system memory
Occlusion Sensitivity	High: 0.02-0.06 Mpa Medium: 0.06-0.09 Mpa Low: 0.09-0.12 MPa
Power Supply, AC	110/230 V (optional), 50/60 Hz, 20 VA
Battery	9.6 ±1.6 V, rechargeable
Battery Life	5 hours at 5 ml/h
Working Temperature	5- 40°C
Relative Humidity	20-90%
Atmospheric Pressure	860-1060 hpa
Size	314167140 mm
Weight	2.5 kgs
Safety Classification	Class II, type CF
