Hematology analyzer
We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive.
1. Big screen with backlight and simple list menu to use easily
2. Easy to operate
3. Powered by 1 AAA alkaline battery, low expenses for patients
4. Available for all brands of infusion sets
5. Dual microprocessors for continuous cross checking to protect safety
6. Doctor Module to care patients
7. Auto lock screen to avoid operation mistakes
8. Auto reset for screw droved by motor from Swiss
9. Auto-calculate the filling insulin
10. Pulse infusion to improve the efficacy, whatever in basal or in bolus
11. Auto memory the bolus setting
12. Much recorders memorized
Display | Liquid Crystal Display (LCD) with backlight, 128*64 dots. Auto display of remaining insulin, battery life, operation status, time and basal rate; Simple list driven menu. |
Dimensions | 78*52*20mm |
Net Weight | 55 grams |
Power Supply | 1 AAA alkaline battery; Display with energy saving sleep mode. |
Insulin Reservoir | 24 basal rates; 305u |
Infusion Frequency | 1~60 times/hour |
Basal Rate Setting | 2u/hour (default); Min. 0.05u/hour; (1) General: 0~2u/hour; (2) For Doctor: 0~5u/hour. |
Temporary Basal Rates | +/- up to 200% in 10% increments available for 24 hours |
Basal Setting | 20u (default); (1) General: 0~40u; (2) For doctor: 0~85u. Adjustable in fixed increments of 0.1u |
Daily Total Setting | 60u (default). (1) General: 60u; (2) For Doctor: 0~200u. |
Filling Method | Auto reset for screw drove by motor; Auto calculate the filling insulin |
Motor | Swiss micro DC motor |
Safety | Safety Check: Dual microprocessors for continuous cross; Safety Settings: Maximum bolus/Maximum basal/Maximum daily total/Low reservoir/ Line occlusion / Low battery/ Pump malfunction/Meal time; Suspension Mode: Manual Suspension; Water Resistant: IPX7 |
Memory of History | Bolus: Last 50 boluses with time and date stamp; Auto memory for the last setting; Daily: Last 50 daily insulin totals with time and date stamp; Prime: Last 50 daily insulin totals with time and date stamp; Alarm: Last 50 daily insulin totals with time and date stamp |
Others | Color: Black; Language: Chinese & English (preset one only in a device) Standard Luer interface for infusion set, all brands of insulin sets use available |
Environment | Condition of Operation: Temperature Range: 5°C~40°C; Air humidity (Relative humidity): 20%-90%; Barometric Pressure: 86kPa ~ 106kPa. Condition of Storage/Transportation: Temperature Range: -20°C~50°C; Air humidity (Relative humidity): 10%-90%; Barometric Pressure: 50kPa ~ 106kPa. |
