LTSI12 Syringe Pump for hospital
No: LTSI12
Type: Syringe and infusion pump
Dimension:
Characteristics:
Drug library contains more than 50 durg names,and can by updated and programmed

Product Features ：

1. Three kinds of modes: Rate Mode, Time Mode, Body Weight Mode;

2. Drug library contains more than 50 durg names,and can by updated and programmed;

3. Powerful alarm system with 360° visual light signs,easy for clinical idendify;

4. User friendly,Unified operation interface for FC1 series syringe pump;

5. Double CPU to ensure system security;

6. Syringe barrel flange clamping slot with syringe dislocation alarm function;

7. Plunger securing slot with syringe dislocation alarm function;

8. Automatically recognize the syringe type--5/10/20/30/50/60ml,complly with all brands;

9. Brand name of syringe is storable after easy callibration;

10. Up to 8 hours battery back up at middle rate;

11. Handy collapsible handle;

12. Fixation clamp which can be 90 degrees rotated;

13. The grip for extension line to keep safe during infusion;

14. Save the preset volume automatically when there is unpredictable switching off;

15. Standard RS232 interface;

16. Event Log with at least 500 history records;

17. Anti-bolus function after occlusion for more accurate and safer infusion;

18. Can be stacked up and integrated into multi-channel between FC1 series syringe pump.

Product Name	LTSI12 Syringe Pump
Wi-Fi	Yes
Drug Library	Yes
Infusion Modes	Rate Mode, Time Mode, Body-Weight Mode
Drug Name Display	More than 50, can be updated
Safety	Double CPU to make sure higher standard infusion
Accuracy	±2%
Time Preset	0~99h and 59min
Volume Range	0.01~9999.99ml
Flow Rate Step by	0.01 ml/h
Flow rate range	5ml Syringe: 0.01ml/h-150ml/h;10ml Syringe: 0.01ml/h-400ml/h;20ml Syringe: 0.01ml/h-600ml/h;30ml Syringe: 0.01ml/h-900ml/h;50/60ml Syringe: 0.01ml/h-1500ml/h;
Purge/Bolus rate/Top flow rate	5ml Syringe: 150ml/h;10ml Syringe: 400ml/h;20ml Syringe: 600ml/h;30ml Syringe: 900ml/h;50/60ml Syringe: 1500ml/h;
KVO	Rate≥10ml/h: KVO=3ml/h;1ml/h≤Rate≤10ml/h: KVO=1ml/h;Rate ≤1ml/h: KVO=Preset rate(Defaulted rate: 0.1 ml/h);
Occlusion Pressure	High: 106.7KPa±26.7 KPa;Middle: 66.7KPa±13.3 KPa;Low: 40.7KPa±13.3 KPa;
Pause Overtime Alarm	1min50s—2min
Power & Battery	25VA, AC:100V-240V 50HZ/60HZ, DC:12V,Lithium battery support more than 8 hours
Classification	Class II,type CF,IPX4
Audible & Visible Alarms	Syringe Dislocation, Occlusion, Near End, Pause Overtime, Low Battery, Battery Exausted, VTBI Completion, Syringe Empty, Motor Malfunction, Incorrect Syringe Specification, Circuit Malfunction, Internal Communication Malfunction, Master CPU Malfunction, Monitoring CPU Malfunction
